CPU

LGA 775 for Intel® Core™ 2 Duo*/ Pentium® XE / Pentium® D / Pentium® 4 / Celeron® D, supporting Conroe processors
FSB 1066 MHz for external graphics (by overclocking)
FSB 800/533 MHz for internal graphics
Supports Hyper-Threading Technology
Supports Untied Overclocking Technology
Supports EM64T CPU

Chipset

Northbridge: Intel® 865G
Southbridge: Intel® ICH5

Hybrid Booster

CPU Frequency Stepless Control
ASRock U-COP
Boot Failure Guard (B.F.G.)

Memory

Dual Channel DDR memory technology
2 x DDR DIMM slots
Supports DDR400/333/266
Max. capacity: 2GB

Slots

3 x PCI slots
1 x AGP 8X slot
1 x AMR slot

VGA

Integrated Intel® Extreme Graphics 2
Max. shared memory 96MB

Audio

Cmedia 9761A 5.1 channel audio CODEC

LAN

Realtek PCI LAN 8101L
Speed: 10/100 Ethernet
Supports Wake-On-LAN

Connector

2 x Serial ATA 1.5 Gb/s connectors
(No Support for "RAID" and "Hot Plug" functions )
2 x ATA100 IDE connectors (support 4 x IDE devices)
1 x Floppy connector
1 x IR header
1 x COM header
CPU/Chassis FAN connectors
20 pin ATX power connector
4 pin 12V power connector
CD in header
AUX in header
Front panel audio connector
2 x USB 2.0 headers (support 4 USB 2.0 ports; 2 of them are shared with USB4_5)

Rear Panel I/O ASRock I/O Plus

1 x PS/2 Mouse Port
1 x PS/2 Keyboard Port
1 x VGA Port
1 x Parallel Port (ECP/EPP Support)
6 x Ready-to-Use USB 2.0 Ports
1 x RJ-45 LAN Port
Audio Jack: Line in / Front Speaker / Microphone

BIOS Feature

4Mb AMI BIOS
AMI Legal BIOS
Supports "Plug and Play"
ACPI 1.1 Compliance Wake Up Events
Supports jumperfree
SMBIOS 2.3.1 Support

Support CD

Drivers, Utilities, AntiVirus Software (Trial Version)

Hardware Monitor

CPU Temperature Sensing
Chassis Temperature Sensing
CPU Overheat Shutdown to Protect CPU Life
CPU Fan Tachometer
Chassis Fan Tachometer
CPU Quiet Fan
Voltage Monitoring: +12V, +5V, +3.3V, Vcore

Accessories

Quick Installation Guide, Support CD, I/O Shield
Floppy/ATA 100 cables
1 x COM port bracket

Form Factor

Micro ATX Form Factor: 9.6-in x 8.0-in, 24.4cm x 20.3cm.
